PULSARLUBE潤滑裝置Pulsarlube M系列技術參數
Technical Specifications | |
Grease Pouch Capacity | 60ml/125ml/250ml/500ml (replaceable) |
Power Supply | DC 4.5V Battery Pack |
Operating Pressure | 30~60bar (435~870psi) |
Operating Temperature | Standard Alkaline Battery : -15?C~60?C (5 ?F~140?F) |
Dispensing Periods | 1~12 month |
Remote Installation | Max. 10m (33ft) with O.D. ?6 tube |
Multi-Point Installation | Max. 6m (20ft) with O.D. ?6 tube (Up to 8 lube points) |
PULSARLUBE潤滑裝置Pulsarlube M系列介紹
Pulsarlube M 由一個垂直進料泵和一個微處理器芯片組成，平均工作壓力為 30bar(435psi)。它旨在確保可靠的潤滑，同時通過節省成本的服務包減少潤滑費用。
Pulsarlube M 機電自動油脂潤滑器主要用于彌補傳統氣體式自動油脂潤滑器的性能。它還在成本競爭力和用戶友好性方面具有卓越優勢。
Pulsarlube M 由一個垂直自吸泵、微處理器控制系統和大型 LCD 顯示屏組成。該產品非常適合以下應用：潤滑管路中存在相當大的背壓，需要精確潤滑，或者一次性氣體式潤滑器不經濟。
特點
30bar
多點潤滑點最多 8 個/最大。單點 10 米（33 英尺）
LCD
內置 LCD 和簡單的按鈕控制，易于編程
-40°C
可選鋰電池組，可用于低溫使用
服務包
使用可更換的潤滑脂袋和電池組可大幅節省成本
The Pulsarlube M consists of a vertical feed pump and a microprocessor chip allowing an average operating pressure of 30bar(435psi). It is designed to ensure reliable lubrication and at the same time reduce lubrication expenses with cost-saving Service Packs.
The Pulsarlube M electromechanical automatic grease lubricator is primarily designed to compensate for the performance of conventional gas type automatic grease lubricator. It also offers superior advantages in cost competitiveness and user-friendliness.
The Pulsarlube M consists of a vertical self-priming pump, microprocessor control system, and large LCD display. This product is ideal for applications where: considerable back pressure in lube line exists, a precise lubrication is required, or a disposable gas type lubricator is not economical.
FEATURES
30bar
Up to 8 lube points for multi-point / Max. 10m (33ft) for single point
LCD
Easy to program with built-in LCD and simple button controls
-40°C
Optional Lithium Battery Pack available for low temperature usage
Service Pack
Substantial savings from the use of replaceable grease pouches and battery packs
PULSARLUBE潤滑裝置Pulsarlube M系列其他常用型號：
PULSARLUBE M60/MAIN
PULSARLUBE M60/PL1
PULSARLUBE M125/MAIN
PULSARLUBE M125/PL1
PULSARLUBE M250/MAIN
PULSARLUBE M250/PL1
PULSARLUBE M500/MAIN
PULSARLUBE M500/PL1 Pu
PULSARLUBE M250/EMPTY
PULSARLUBE LUBRICATOR NEW + ORIGINAL+ ONE YEAR WARRANTY
