Performance

Measurement range

–100 to +20°C dew point
  –110 to +20°C dew point

Accuracy

±2°C dew point

Response time

5 mins to T95 (dry to wet)

Repeatability

0.5°C dew point

Calibration

Traceable 7-point calibration certifi cate

Electrical Specifi cations

Output signal

4–20 mA (2-wire connection, current source) User confi gurable over range

Output

Dew point or moisture content for ppmV

Analog output scaled range

Dew point: –100 to +20°C
  Moisture content in gas: 0–3000 ppmV
  Non-standard available upon request

Supply voltage

12 to 28 V DC

Load resistance

Max 250 Ω @ 12 V (500 Ω @ 24 V)

Current consumption

20 mA max

CE marked

Certifi ed

Operating Specifi cations

Operating temperature

–40 to +60°C

Compensated Temperature Range:

20 to +50°C
  NOTE: The transmitter accuracy statement is
  only valid for the temperature range: -20/+50°C

Storage Temperature

-40 to +60°C

Operating pressure

45 MPa (450 barg) maximum

Overpressure rating

x2 operating pressure 90 MPa (900 barg)

Flow rate

1 to 5 Nl/min mounted in standard sampling block; 0 to 10m/sec direct   insertion
