Locking

screw up the knurled ring on the cable connector 1/6 of a turn on the panel connector barrel, for frequent locking and unlocking

Protection

IP 50 to IP 54 with conexil in the housing with flat-gasket for panel connector

Contacts

3 to 17 contacts ? 2 mm – ? 3 mm – ? 4 mm non-removable solder contacts

Max. current

15A ? 2 mm – 35A ? 3 mm – 50A ? 4 mm

Contact resistance between pin and socket

< 1,5mΩ ? 2 mm – < 1mΩ ? 3 mm – < 0,7mΩ ? 4 mm

Breakdown voltage between adjacent contacts

> 2500 Volts (RMS)

Breakdown voltage between peripheral contacts and ground

> 1500 Volts (RMS), (> 2000 Volts (RMS) 4 contacts ? 4mm)

Insulation resistance

> 107MΩ at 20 °C –> 105MΩ at 100 °C

Operating temperature

-40 °C to +100 °C (500 hours at +125 °C)

Materials

Nickel-plated light alloy, gold-plated brass contacts, PBT insert

Max. cross-section of soldered conductors

1,34 mm2 ? 2 mm – 3,18 mm2 ? 3 mm – 5,26 mm2 ? 4 mm
