ABNOX注油泵PT-40622.00-EC產品規格
Technical Data | |
Suction tube dia. [mm] | 32 |
Input medium specification | Lubricants up to NLGI 3 / 5'000 mPa.s |
Delivery rate at pump outlet [cm3/min] | 1295 |
Delivery rate per double stroke [cm3] | 17 |
Working pressure medium outlet at pneumatic operating pressure 6 bar [bar] | 140 |
Working pressure medium outlet at pneumatic operating pressure 10 bar [bar] | 233 |
Connection medium outlet external thread | 1/4'' BSP |
Compressed air quality | ISO 8573-1:2020 [6:4:4] |
Max. air consumption [l/min.] | 217 |
Optimum pneumatic operatingpressure [bar] | 6 |
Min. / max. pneumatic operating pressure [bar] | 2/10 |
Pneumatic connection internal thread | 1/4'' BSP |
Min. / max. operatingtemperature [°C] | 10/40 |
ABNOX注油泵PT-40622.00-EC產品介紹
空氣操作的25:1型S型潤滑脂泵適用于轉移中高粘度的潤滑劑。此S型泵適用于輸送粘度高達60,000厘斯的硅脂和硅油。不適用于固化和磨蝕性介質，或含有磨蝕性填充物的介質！
吸入系統和氣動馬達的獨立設計可防止介質可能滲透到泵頭中。
這種壓力比為25:1的潤滑脂泵非常適合作為ABNOX計量閥或填充系統的供給泵。
空氣操作單泵25:1 型號S 2010版本
貨號：見表
型號：比率25:1 型S
設計：容器高度280-840毫米
The Air-operated Grease Pump 25:1 from type S is suitable for transferring lubricants of medium to high viscosity levels. This type S Pump is qualified for delivering silicon greases and silicon oils with a viscosity up to 60'000 cST. Not suitable for hardening and abrasive media, or with abrasive filling substances!
The separate design of Suction System and Air Motor prevents a possible permeation of the medium into the Pump Head.
This Grease Pump with pressure ratio from 25:1 is ideal applicable as Feeding Pump for ABNOX Metering Valves or as Filling System
Air-operated Single Pump 25:1 Type S Version 2010
Article No.：see table
Modell：Ratio 25:1 Type S
Design：Container height 280-840 mm
ABNOX注油泵其他常用型號：
ABNOX PT-40622.00-EC
ABNOX 4062010
ABNOX 4062100
ABNOX 4062200
ABNOX 4062300
ABNOX 4062400
ABNOX Oil filling pump NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向制造工業提供高端制造技術和設備。代理經營世界優質的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于ABNOX注油泵PT-40622.00-EC的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for ABNOX products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:www.aalatcr.cn.
