WAN Connectivity

Ethernet or WiFi 802.11 b/g/n.

Frequencies

Channels: 1 to 11(inclusive).

Security

WPA2, WPA and WEP.

Antenna Connector

RP-SMA female connector.

Antenna

Included in the delivery; frequency: 2.4GHz; impedance: 50 Ohms; gain: 2.0dBi.

WAN Ethernet

Up to 3 ports, 10/100 Mb Ethernet.

LAN Ethernet

Up to 4 ports, 10/100 Mb Ethernet.

Field interface

Up to 10 USB 2.0 connections, female connector 2.0

SD Card reader

YES, for Cosy commissioning (firmware upgrade, backup, Talk2M registration).

Router

IP filtering, IP forwarding, NAT, Port forwarding, Proxy, Routing table, DHCP client/server.

Internet

Outbound connection for Talk2M using HTTPS (port 443 or UDP 1194).

VPN Tunneling

OpenVPN either in SSL UDP or HTTPS.

Talk2M

Talk2M Free+ or TalK2M Pro, natively supported.

VPN Security

Communications between the remote user and the Ewon are fully encrypted using the SSL/TLS protocol, thereby ensuring data authenticity, integrity & confidentiality. All users and Ewon units are authenticated using x509 SSL certificates and end-to-end traffic is encrypted using strong symmetric & asymmetric algorithms that are part of the SSL/TLS protocol cipher suite.

Synchronization

Embedded real-time clock, manual setup via http or automatic via NTP.

File Management

FTP server for configuration, firmware update.

Web-based configuration

Embedded web interface with setup wizards for configuration and maintenance (no additional software needed). Basic authentication (login/password) and session control for security.

Mechanicals

Dimensions: 108,80 x 99 x 43,60 mm (H x D x W).
DIN rail or wall screw fixing system.

Weight

214 gr.

Power supply

12-24 VDC +/-20%, LPS.

Extended Temperature Range

Operating: -25°C to +60°C, 10 to 95% relative humidity (non-condensing).
Storage: -40°C to +60°C, 10 to 95% relative humidity (non-condensing).

Hardware

1xDO: open drain ( MOSFET) 200mA; isolation 1.5kV,
2xDI: 0 to 24VDC; 1.5 kV isolation.

Marking

CE, cULus, FCC.
