Power supply range

AC 19.2 ... 28.8 V / DC 21.6 ... 28.8 V

Power consumption In operation
                                 For wire sizing

1.5 W at nominal torque
2.5 VA

Connecting cable

Cable 1 m, 4 x 0,75 mm2

Parallel connection

Yes (Note performance data for supply!)

Functional data

Torque (nominal torque)

Min. 10 Nm at nominal voltage

Control  control signal Y
              operating range

DC 0 ... 10 V, Input resistance 100 k?
DC 2... 10 V for 0 ... 90°
(can be switched to DC 0 ... 10 V)

Position response (measuring voltage U)

DC 2... 10 V, max. 1 mA, for 0 ... 90° )
(can be switched to DC 0 ... 10 V)

Position accuracy

±5%

Manual override

Temporary and permanent disengagement of the gearing latch by means of the rotary knob on the housing

Safety

Running time

140 s / 90°

Sound power level

Max. 35 dB (A)

Position indication

Scale plate 0 ... 1

Protection class

III Extra low voltage

Degree of protection

IP40

EMC

CE according to 89/336/EEC

Mode of operation

Type 1 (to EN 60730-1)

Rated impulse voltage

0.8 kV (to EN 60730-1)

Control pollution degree

3 (to EN 60730-1)

Ambient temperature range

0 ... +50°C

Media temperature

+5 ... +120°C (in ball valve)

Non-operating temperature

–30 ... +80°C

Ambient humidity range

95% r.H., non-condensating (to EN 60730-1)

Maintenance

Maintenance-free

Weight

Approx. 500 g (without ball valve)
