ELECTRICAL

Input Voltage:

105-135 volts AC, 50/60 Hz.
210-250 volts AC, 50/60 Hz. (Special Order)
24 volts AC/DC, 50/60 Hz. (Special Order)

Output:

DPDT relay to 3 Amp. Resistive at 120 volts AC
DPDT relay to 3 Amp. Resistive at 240 volts AC
DPDT relay to 3 Amp. Resistive at 30 volts DC
1/10 Horsepower at 120 volts AC
1/10 Horsepower at 240 volts AC

Ambient Temperature Range:

14°F to +131°F (-10°C to +55°C)

Max. Operating Temperature (CMS-X):

Class T6: 85°C (185°F)

Repeatability:

+2% maximum at constant voltage and temperature.

Power Consumption:

3 Watts

Pick-up Point:

3 speed ranges at which relay will energize:
LOW:0.1 to 10 RPM
MEDIUM:1 to 100 RPM
HIGH:10 to 1000 RPM

Signal Point:

Speed at which relay will de-energize. Recommended to be 15- 20% lower than pick-up point to eliminate nuisance shutdowns.

Start-up Delay:

Adjustable up to 45 seconds.

MECHANICAL

Radial Load on Input Shaft:

125 lb (56.25 kg) Maximum

End Thrust on Input Shaft:

100 lb (45 kg) Maximum.

Rotation:

Either clockwise or counter-clockwise

Driving Torque:

1”/lb (0.11 N*m) maximum.

Shaft:

5/8” (16 mm) diameter w/ 3/16” x 7/8” (5 x 22 mm) key

Enclosure:

Aluminum w/screw cover

Meets:

CMS-G:NEMA Types 3S, 4 & 4X
CMS-X:NEMA Type 7: Class I groups C & D
NEMA Type 9: Class II groups F & G
120 VAC units CULUS Listed

Bearings:

Ball, permanently lubricated and sealed for life.

Shaft Seal:

Leather type oil seal.

Weight:

5 lb (2.25 kg)

Size:

5” high x 5” wide x 8-1/2” long (127 x 127 x 216 mm)
