Weight

16.2 kg

Size

630 mm

Motor size

110

Rotor surface

Cast in aluminum

Terminal box material

PP plastic

Blade material

Sheet aluminum insert, sprayed with PP plastic

Guard grille material

Steel, coated with black plastic (RAL 9005)

Number of blades

5

Blade pitch

-10°

Airflow direction

V

Direction of rotation

Counterclockwise, viewed toward rotor

Degree of protection

IP54

Insulation class

F

Moisture (F) / Environmental (H) protection class

H2

Ambient temperature note

Occasional start-up at temperatures between -40°C and -25°C is permitted.
For continuous operation at ambient temperatures below -25°C (such as refrigeration applications), use must be made of a fan design with special lowtemperature bearings.

Installation position

Shaft horizontal or rotor on bottom; rotor on top on request

Condensation drainage holes

On rotor side

Mode

S1

Motor bearing

Ball bearing

Touch current according to IEC 60990
(measuring circuit Fig. 4, TN system)

<= 3.5 mA

Electrical hookup

Terminal box

Motor protection

Thermal overload protector (TOP) with basic insulation

with cable

Axial

Protection class

I (with customer connection of protective earth)

Conformity with standards

EN 60034-1 (2010); CE; UKCA

Approval

VDE; CCC; EAC
