SENSOREX位移傳感器SX40000系列產品介紹

Meggitt (Sensorex) selected the best MEMS cells available on the market and associated them to the digital signal compensation and processing stage to obtain a tilt sensor that matches the key performances of servo-inclinometers, at an optimized cost.

It achieves a maximum scale factor non-linearity error <0.05% Full Scale, a maximum bias calibration residual error on [-40°C/+85°C] of ±0.057° and a maximum scale factor calibration residual error on [-40°C/+85°C] of ±0.5%.

SX40000 tilt sensor achieves superior performances under vibrations (low bias rectification error, low noise) with the use of over-damped sensitive elements and a very innovative differential measurement principle. Furthermore, the sensitive elements are designed to withstand very high g shocks (200g/ 6ms).

Power supply can span from +4.5 to +30VDC. This unit is available in 6 different ranges, ±3°, ±14.5°, ±70°. Signals are made available to the end-user as 4-20mA, RS485 and USB outputs.

Specifically designed to operate in stringent vibratory environments, one of the key parameters of our MEMS tilt sensor is its adjustable bandwidth between 0.01Hz and 10Hz (thanks to a configurable digital filter).

A complete auto test is automatically made at the start of the sensor and results are transmitted to the digital outputs and to the TOR BIT-OUT output.

Applications

Robotics

Safety purposes (cranes, platforms…)

Civil engineering monitoring (alignment of structures)

Industrial & machining equipment

Antenna positioning

Meggitt (Sensorex) 選擇了市場上最好的 MEMS 單元，并將它們與數字信號補償和處理階段相關聯，以優化成本獲得與伺服測斜儀的關鍵性能相匹配的傾斜傳感器。

它實現了最大比例因子非線性誤差 <0.05% 滿量程，[-40°C/+85°C] 上的最大偏置校準殘差為 ±0.057°，最大比例因子校準殘差為 [-40 °C/+85°C] ±0.5%。

SX40000傾角傳感器采用過阻尼敏感元件和非常創新的差分測量原理，在振動下（低偏置整流誤差、低噪聲）實現了卓越的性能。 此外，敏感元件設計為可承受非常高的 g 沖擊 (200g/6ms)。

電源范圍為 +4.5 至 +30VDC。 該裝置有 6 個不同的范圍，±3°、±14.5°、±70°。 信號以 4-20mA、RS485 和 USB 輸出的形式提供給最終用戶。

MEMS 傾斜傳感器專為在嚴苛的振動環境中運行而設計，其關鍵參數之一是其在 0.01Hz 和 10Hz 之間的可調帶寬（得益于可配置的數字濾波器）。

傳感器啟動時會自動進行完整的自動測試，并將結果傳輸到數字輸出和 TOR BIT-OUT 輸出。

應用

機器人技術

安全目的（起重機、平臺……）

土木工程監測（結構對齊）

工業和加工設備

天線定位
