Cartridge Part Number

MIDAS-S-HFX
  MIDAS-E-HFX

Sensor Technology

3 electrode electrochemical cell

Measuring Range

HF0-12ppm

Minimum Alarm 1 Set Point

1.45ppm

Lower Detection Limit

1.05ppm

Linearity

<±10%of measured value

Repeatability

<±10%of measured value

Resolution

0.05ppm

Response Time t625

≤30 seconds

Sensor Cartridge Life Expectancy

≥24 months under typical application conditions

Operating Temperature
  Effect of Temperature
  Zero
  Sensitivity

0℃ to +40℃(32°to 104°F)

  <±0.008ppm/℃
  <±0.4%of measured value/℃

Operating Humidity
  Effect of Humidity
  Zero
  Sensitivity

10 to 90%RH

  <±0.003ppm/%RH
  <±1%of measured value/%RH

Operating Pressure

90-110kPa

Effect of Position

No effect in typical application

Long Term Dift
  Zero
  Sensitivity

  No drift
  <15%of measured value/year

Calibration Gas

Hydrogen Fluoride (HF)

Bump Test Gas

Chlorine (Cl2)

Warm Up Time

<20 minutes

Storage Temperature

+5℃ to+25℃(+41°F to+77"F)
