規格描述

VITEC速度傳感器602885-49R 4033-400產品參數

Specification
Measurement Mode	Velocity
Bearing Type	Anti-Friction Sleeve with Shaft Rider
Applications	Turbines, Generators, any equipment running 1200 to 90000 RPM and up to 400oF
DYNAMIC
Output	200 mV Peak ±3% for 1.0 in/sec Peak into a 10K ohm Resistive Load at 100 Hz
Linearity	±2 (From 0.2 to 8.0 in/sec Peak) ±3 (From 0.1 to 10.0 in/sec Peak)
Frequency Response	20 to 1500 Hz, ±5%
Transverse Axis Sensitivity	5% at 100 Hz
Natural Frequency	20 Hz (Approximate)
Temperature Sensitivity (Change in output from 20 to 1000 Hz)	±5% (with a temperature range of 25-400°F)
Amplitude Range (Inches)	0.0002 (Minimum) 0.100 (Maximum)
Operating Gs, Maximum	17
Damping	Electro-Magnetic
ELECTRICAL
Power Requirements	None, Self Generating
Sensing Element Impedance	230 ohms, ±10% at 75°F
Grounding, Sensing Element	Internally ungrounded
Connections (Connector)	Pin A- Signal Pin B- Open Pin C- Signal Return
ENVIRONMENTAL
Temperature Range	-20 to 400 oF
Hazardous Area Rating (When Installed per Vitec Drawing 623813-137)	Intrinsically Safe for Class 1, Group D, Div 1
Operating Position (Degrees from Vertical, Connector Up)	±110
PHYSICAL
Vitec Part No.	602885-49R
Case Material	2024-T3 Aluminum with Satin Anodized Finish
Height (Inches)	4.92
Body Diameter (Inches)	1.97
Center Mounting Hole	1/4-28 UNF x 1/4 in Deep
Mating Cable Assembly	Varies with application, contact factory
Weight (Oz)	28

產品介紹

愛澤工業（ize-industries）并不是本網站所列所有產品的授權代理商或經銷商。本網站使用的所有產品名稱，商標，品牌等均屬于各自品牌廠家所有。本網站在產品或圖片描述中，出現具有這些名稱，商標，品牌等信息的產品僅用于識別目的，并非旨在表明任何與持有者的從屬及授權關系。

VITEC速度傳感器602885-49R 4033-400產品介紹

測量從2到10,000 Hz的振動頻率，非常適合從冷卻塔風扇到高速齒輪箱的機器，

提供穩定，低阻抗的輸出，適用于長達1000英尺的電纜線

設計有重型連接器和陽極氧化鋁外殼，可承受堅固的環境工業應用。

Measure vibration frequencies from 2 to 10,000 Hz, ideal for machines ranging from cooling tower fans to high speed gear boxes

Provide stable, low-impedance outputs for cable runs to 1,000 feet

Designed with heavy-duty connectors and anodized aluminum housings to stand up to rugged industrial applications.

外觀尺寸圖

VITEC速度傳感器602885-49R 4033-400其他常見型號

VITEC 602885-49U 4032-300

VITEC 602885-49R 4033-400

VITEC 602885-49Y 4033-500

VITEC 412585-159A 4034
