Operation Mode

Diffuse Proximity

Function

Both

Supply Voltage

10 - 30 V dc

Light Source

Infrared (880 nm)

Control Feature

Sensitivity pot. and light/dark switch

Sensing Range

0,5 m

Output

PNP

Output Status

N.C./N.O.

Housing

M18 x 1

Housing Material

Stainless Steel

Connection

4 pin, M12 plug

Technical Data

Supply Voltage

10 - 30 V dc

Voltage Ripple

0.15

Reverse Polarity Protected

Yes

Short Circuit Protected

Yes

Current Consumption

14 mA

Max. Output Load

120 mA / 30 V dc

Max. Residual Voltage

1,5 V

Max. Operation Frequency

250 Hz

Response Time ton / toff

2 ms / 2 ms

Power On Indicator

Green LED

Output Indicator

Yellow LED

Hysteresis

Approx. 5 - 15 %

Opening Angle

+/- 4°

Housing Material, Front Lens

Polycarbonate

Housing Material, Sensor Housing

Stainless Steel (AISI 316 / 1.4401)
