AMTRON存儲卡CFC-SI001GIAU產品參數
Specification | |
Meets military standard | MIL-STD-810F |
National Stock Number (NSN) assigned by Defense Logistics Agency (DLA) | |
Single-level cell (SLC) NAND flash technology | |
Metal casing | optional plastic casing is available |
RoHS compliant | [Lead free] |
CompactFlash Type I form factor | (3.3mm thick) |
Compliant with CompactFlash specification 4.1 | |
Compliant with PCMCIA 2.1 standard | |
Operating temperature | 40℃ ~ +85℃ [optional 0°C to +70°C temperature is available] |
Shock | 2000G; Vibration: 15G peak to peak ; Altitude: 50,000 feet |
Dual voltage operation | 3.3V or 5V |
Very low power consumption | |
Supports S.M.A.R.T command | |
High speed: Read: 43 MB/sec Max. ; Write: 35 MB/sec Max | |
MTBF | >3,000,000 hours |
Automatic error correction and retry capabilities | |
True IDE interface modes / supports PIO mode 0-6, MDMA mode 0-4, UDMA mode 0-4 | |
Auto-sensing | automatically switch to fixed disk mode on IDE bus or removable disk mode on PCMCIA bus; also automatically detect data transfer mode and switch to PIO mode, MDMA mode, or UDMA mode [ Optional disk and data transfer modes, with suffix FP/FM/FU/RP/RM/RU/AP/AM are available at the same price ] |
1 year warranty | |
AMTRON存儲卡CFC-SI001GIAU產品介紹
自動感應：自動切換到IDE總線上的“固定磁盤模式”或PCMCIA（PC卡）總線上的“可移動磁盤模式”；還可以自動檢測數據傳輸模式并切換到“ PIO模式”或“超DMA（UDMA）模式”。
可用選項 ： 帶有后綴 FP / FU / RP / RU / AP的不同磁盤模式和數據傳輸模式與 AU的價格相同。
Auto Sensing:Automatically switch to "fixed disk mode" on IDE bus or "removable disk mode" on PCMCIA (PC Card) bus; also automatically detect data transfer mode and switch to "PIO mode" or "Ultra DMA (UDMA) mode".
Available Options:Different disk modes and data transfer modes, with suffix FP/FU/RP/RU/AP, are available at the same price as AU.
AMTRON存儲卡CFC系列其他常見型號：
AMTRON MTR11 CFC-SI128MIAU
AMTRON MTR11 CFC-SI256MIAU
AMTRON MTR11 CFC-SI512MIAU
AMTRON MTR11 CFC-SI001GIAU
AMTRON MTR11 CFC-SI002GIAU
AMTRON MTRMP CFC-SI004GIAU
AMTRON MTRMP CFC-SI008GIAU
AMTRON MTRMP CFC-SI016GIAU
AMTRON Memory Cards NEW + ORIGINAL+ ONE YEAR WARRANTY
愛澤工業成立于2010年，定位于向先進制造工業提供高端制造技術和設備。代理經營世界先進的電氣自動化、機械與傳動、流體控制、儀器儀表、工具等產品。作為電氣，液壓以及氣動解決方案的合作伙伴，我們利用我們的全球協作團隊，為客戶提供先進解決方案，市場知識以及相關增值服務來幫助優化客戶的工作效率，提高可靠性和安全性，致力于成為工業產品和解決方案的優質渠道。
如果有任何關于AMTRON存儲卡CFC-SI001GIAU的疑問，請隨時與我們溝通（021-31006702）。我們將盡全力解決您的問題。
If you have any question for AMTRON products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:www.aalatcr.cn.
